Key Features
- High gain (min 5 dBi) across all cellular bands
- Industrial grade weatherproof fibreglass radome
- Highest practical wideband gain
- Carrier aggregation ready
- Wide spectrum design, suits all current and planned networks (including 700 MHz 4GX).
Additional Information
- This heavy duty multiband omnidirectional antenna sports an extremely wide bandwidth design – operating on two bands 698-960 MHz, 1710-2700 MHz covering all 2G, 3G, and 4G cellular bands with high gain and high efficiency
- Being broadcast grade, this antenna is ideal for LTE small cell deployments
- This is the only high gain omnidirectional antenna on the market capable of covering Telstra and Optus 4GX and 4G+ 700 MHz (Band 28) and 2600 MHz (Band 7) networks, as well as standard 1800 MHz 4G (Band 3).
- For best 4G performance two antennas should be operated to provide MIMO
- MIMO Bracket available separately
- This is an ideal antenna for remote telemetry and mobile/semi-mobile stations
- Unlike some base station antennas, which have lossy coaxial cable, this antenna has an integrated N Female connector located at its base, allowing for direct attachment of low loss feeder/riser cables
- Designed specifically for mast mounting, the antenna’s heavy duty aluminium mounting tube can be mounted using the supplied parallel U-bolt clamp.
Usage
- With the different range of frequencies – Telstra and Optus activated 700 and 2600 MHz networks, Vodafone starting a long range 850 MHz 4G network, Optus operating a 2300 MHz TDD network in some areas, and Telstra running 900 and 2100 MHz 4G in others – deploying a 4G antenna can be a nightmare
- Take full advantage of the blistering fast speed your 4G network offers – regardless of frequency, with this high performance carrier-aggregating antenna.
